Ceiling Speaker CA-810

Highlight Features

CA-810 – CA Ceiling Speaker

The CA-810 is a ceiling-mounted speaker from the CA Ceiling Speaker series, designed for 70V/100V public address and background music systems. With a compact structure, durable ABS enclosure, and clear sound reproduction, it is ideal for offices, schools, shopping malls, hospitals, corridors, and commercial buildings.

Product Description

• 70V/100V ceiling speaker: Suitable for PA and BGM systems with multi-zone distribution.
• 10W rated power: Optimized for clear voice announcements and stable background music.
• Selectable power taps (5W–10W): Allows flexible volume matching for different areas.
• 5.25-inch paper cone woofer: Ensures natural midrange and intelligible speech.
• Coaxial tweeter design: Enhances high-frequency detail and sound coverage.
• Pure virgin ABS enclosure: Lightweight, durable, and suitable for long-term ceiling installation.
• Easy installation: Standard cut-out size for quick and efficient mounting.

Product Specification

• Model: CA-810
• Series: CA Ceiling Speaker
• Rated Power: 10W
• Max Power: 15W
• Power Taps: 5W–10W
• Rated Voltage: 70V–100V
• Enclosure Material: Pure virgin ABS plastic
• Color: White
• Woofer Size: 5.25″ (135 mm)
• Woofer Magnet: Φ70 × 15 mm
• Woofer Cone: Paper cone
• Treble Speaker: Coaxial tweeter
• Sensitivity: 95 ± 3 dB
• Frequency Response: 60 Hz – 20 kHz
• Dimensions: Φ203 × 62 mm
• Install Hole: Φ166 mm
• Package Dimension: 64.2 × 43.2 × 35.2 cm / 18 pcs
