Ceiling Speaker CX-830V

Highlight Features

Ceiling Speaker CX-830V

The CX-830V is a two-way ceiling speaker developed for commercial audio systems that require greater output, flexible power configuration, and clear reproduction of both music and speech. Combining an 8-inch paper-cone woofer with a dedicated 1-inch tweeter, the speaker delivers broad frequency coverage while maintaining a discreet appearance within the ceiling. It is suitable for hotels, restaurants, retail stores, offices, schools, conference areas, and other distributed indoor sound systems.

Product Description

• Two-way speaker configuration: An 8-inch woofer and 1-inch tweeter work together to reproduce deeper low frequencies, intelligible vocals, and detailed high-frequency content.
• Flexible power selection: Multiple power taps of 3.8 W, 7.5 W, 15 W, and 30 W allow installers to adjust output according to room size, coverage requirements, and system design.
• Distributed audio compatibility: Rated for 70 V–120 V operation, the CX-830V can be integrated into multi-speaker public-address and background music systems.
• Higher sound output: A rated power of 30 W and maximum power of 50 W provide sufficient headroom for larger commercial rooms and areas with higher ambient noise.
• Broad frequency reproduction: The 60 Hz–22 kHz response range supports natural speech, balanced background music, and clearer high-frequency detail.
• Efficient acoustic performance: With a sensitivity of 93 dB, the speaker produces strong output while making effective use of the available amplifier power.
• Durable ABS construction: The enclosure is manufactured from pure virgin ABS for a lightweight, clean, and reliable ceiling-mounted structure.
• Discreet architectural integration: Its circular white finish blends naturally with common ceiling designs in commercial and public indoor environments.

Product Specification
