Full-Range Speaker KP-615

Highlight Features

KP-615 – 2-Way 15” Full-Range Speaker

The KP-615 is a high-power 2-way 15-inch full-range speaker engineered for demanding professional sound reinforcement applications. Delivering deep, powerful bass, clear high-frequency detail, and exceptional SPL performance, KP-615 is housed in a premium CNC-built birch plywood enclosure. With flexible rigging options and a 35 mm pole mount, it is ideal for large venues, live performances, fixed installations, and mobile PA systems.

Key Features:

• 2-way full-range loudspeaker designed for professional live sound and installation.

• 15-inch LF driver with 75 mm voice coil for deep, powerful low frequencies.

• 34 mm compression HF driver delivers clear and articulate high frequencies.

• High power handling rated at 800W RMS and up to 1500W peak.

• Extended frequency response from 32 Hz to 20 kHz (±3 dB).

• High sensitivity and SPL suitable for large indoor and outdoor venues.

• Flexible installation options with multiple flying points and pole-mount support.

• Rugged enclosure built from CNC-machined high-density fiberboard (HDF).

Technical Specifications:

• Model: KP-615

• LF Driver: 1 × 15″ Woofer (75 mm voice coil)

• HF Driver: 1 × 34 mm Compression Driver

• Power Rating: 800W RMS / 1500W Peak

• Frequency Response: 32 Hz – 20 kHz (±3 dB)

• Sensitivity: 125 dB / 1W / 1m

• Maximum SPL: 130 dB (RMS), 138 dB (Peak)

• Nominal Impedance: 8 Ω

• Coverage Pattern: 70° × 60° (H × V)

• Rigging Hardware: 12 × M8 flying points

• Handles: 2 side handles

• Pole Mount: 35 mm pole socket

• Connectors: 2 × NL4 (pins +1 / −1)

• Enclosure: CNC-built High-Density Fiberboard (HDF)

• Net Weight: 24.5 kg

• Dimensions (W × D × H): 426 × 431 × 684 mm
