Full Range Speaker KPM-12

Highlight Features

KPM-12 – 12” Coaxial Full-Range Monitor Speaker

The KPM Series 12” is a professional 2-way coaxial full-range loudspeaker, engineered to deliver powerful bass response, precise midrange, and clear high frequencies with excellent phase coherence. Thanks to its coaxial driver design, the KPM offers a focused sound image and consistent coverage, making it especially suitable for stage monitoring, live sound reinforcement, and fixed installations. The rugged CNC-machined high-density MDF enclosure, combined with flexible rigging options and a 35 mm pole mount, ensures reliability for both mobile and permanent setups.

Key Features:

• 12” coaxial driver design for accurate phase alignment and clear sound projection.

• High power handling delivers strong output with controlled distortion.

• Wide frequency response ensures deep lows and detailed highs.

• High SPL capability suitable for demanding live performance environments.

• Optimized coverage pattern for effective on-stage and front-fill monitoring.

• Tour-ready enclosure made from CNC-machined high-density MDF.

• Flexible installation with flying points, pole mount, and multiple NL4 connectors.

Technical Specifications:

• Coaxial Driver (LF Unit): 1 × 12″ coaxial driver (75 mm voice coil)

• Power Rating: 800W RMS / 1400W Peak

• Frequency Response: 35 Hz – 20 kHz (±3 dB)

• Sensitivity: 122 dB (1W / 1m)

• Maximum SPL: 128 dB (RMS), 134 dB (Peak)

• Nominal Impedance: 8 Ω

• Coverage Pattern: 60° × 40° (H × V)

• Rigging Hardware: 4 × M8 flying points

• Handles: 2 ergonomic side handles

• Pole Mount: 35 mm pole socket

• Connectors: 4 × NL4 sockets (pins +1 / −1)

• Enclosure: High-density MDF, CNC-machined

• Net Weight: 18 kg

• Dimensions (W × D × H): 400 × 470 × 328 mm
