HD Conference PTZ Camera MC-TC59

Highlight Features

MC-TC59 – HD Conference PTZ Camera

The MC-TC59 is a professional HD PTZ conference camera designed for intelligent video tracking and high-quality video capture in modern meeting rooms, boardrooms, and conference halls. Equipped with a 1/2.8-inch high-quality HD CMOS sensor and advanced digital zoom up to 16×, MC-TC59 delivers sharp, smooth, and detailed images even in low-light environments. With full support for VISCA, Pelco-D, and Pelco-P protocols, it integrates seamlessly with MC Series video processors and conference control systems.

Key Features:

• Full HD 1080p imaging with 1/2.8-inch high-quality CMOS sensor.

• Advanced digital zoom up to 16× for clear close-ups.

• Wide pan & tilt range (±170° pan, −30° to +90° tilt) for full room coverage.

• Low-light performance with 0.5 lux sensitivity.

• Multiple video outputs via HDMI and DVI.

• PTZ protocol support (VISCA / Pelco-D / Pelco-P).

• High preset capacity up to 255 camera positions.

• Network control via Gigabit RJ45 Ethernet.

Technical Specifications:

• Model: MC-TC59

• Image Sensor: 1/2.8-inch HD CMOS

• Effective Pixels: 1080p

• Video Output: DVI / HDMI

• Digital Zoom: 10× (Enhanced up to 16×)

• Focus Control: Auto / Manual

• Minimum Illumination: 0.5 lux @ F1.8 (AGC ON)

• Viewing Angle: 6.3° (Tele) – 72.5° (Wide)

• Signal-to-Noise Ratio: > 55 dB

• Control Protocols: VISCA / Pelco-D / Pelco-P

• Baud Rates: 115200 / 9600 / 4800 / 2400 bps

• Control Interface: RS-485 / RS-232

• Preset Capacity: 255 presets (10 via remote)

• Electronic Shutter: 1/30 s – 1/10,000 s

• White Balance: Auto / Manual / One-push / One-touch / Custom / Indoor / Outdoor

• Noise Reduction: 2D & 3D DNR, BLC supported

• Pan Range: ±170°

• Tilt Range: −30° to +90°

• Pan Speed: 1.7° – 100°/s

• Tilt Speed: 1.7° – 69.9°/s

• Network Interface: RJ45, 10M / 100M / 1000M adaptive

• Power Interface: DC 12V (JEITA standard)

• Input Current: 1000 mA

• Power Consumption: 12 W

• Operating Temperature: 0°C – 40°C

• Storage Temperature: −40°C – 60°C

• Dimensions (D × W × H): 146 × 169 × 168 mm

• Net Weight: approx. 1.5 kg
