IR Transceiver Unit MC-6800RT

Highlight Features

MC-6800RT – IR Transceiver Unit

MC-6800RT is an infrared transceiver unit for the MC-6800 conference system, designed to transmit and receive infrared signals between the central control unit and conference microphones. With a wide coverage angle, high signal gain, and low-power design, MC-6800RT ensures stable and accurate signal distribution in medium to large conference rooms.

Product Description

• Infrared Conference System IR transceiver (transmit & receive).
• Provides wide coverage angle up to 150° for reliable signal distribution.
• High signal gain greater than 40 dBm for stable long-distance transmission.
• Low-power consumption design for continuous system operation.
• Quick installation with mounting hooks.
• Supports wall, ceiling, suspended ceiling, and hard ceiling installation.
• Ideal for boardrooms, conference halls, government and corporate meeting systems.

Product Specification

• Carrier Frequency Band: 4 MHz – 8 MHz
• Power Supply: DC 24 V
• Rated Current: 380 mA
• Rated Power Consumption: 380 mA @ 24 V (≈ 9.1 W)
• Receiving Sensitivity: −120 dBm
• Signal Gain / Amplification: > 40 dBm
• Input / Output Impedance: 50 Ω
• Connector Type: TNC
• Interface: TNC (female)
• Dimensions: Ø145 mm
• Net Weight: 1.71 kg
