Passive Column Speaker FS-44

Highlight Features

Passive Column Speaker FS-44

The FS-44 is a high-sensitivity passive column speaker designed to project clear speech and detailed programme audio across acoustically demanding spaces. Its four 4-inch woofers and neodymium compression driver deliver higher output than a conventional compact column while maintaining a slim architectural profile. The speaker is well suited for conference facilities, houses of worship, lecture halls, event venues, live sound systems, and compact line array installations.

Product Description

• Four-driver column configuration: Four 4-inch woofers work together to improve midrange presence, vocal projection, and overall acoustic output.
• Neodymium compression driver: The 1-inch high-frequency driver reproduces speech articulation and musical detail with greater clarity.
• High acoustic sensitivity: A sensitivity rating of 99 dB allows the FS-44 to generate strong sound pressure with efficient amplifier power usage.
• Focused audience coverage: The 80° horizontal by 30° vertical dispersion pattern directs sound toward the listening area while reducing unnecessary ceiling and floor reflections.
• Professional output capability: The speaker reaches 112 dB continuous and 118 dB peak SPL for demanding speech and music reinforcement applications.
• Wide programme response: A frequency response of 70 Hz–20 kHz supports clear vocals, background music, and general full-range audio reproduction.
• Durable plywood enclosure: The CNC-machined high-density plywood cabinet provides structural rigidity and dependable acoustic performance.
• Flexible suspension options: Twelve M8 threaded rigging points support secure installation in fixed and portable sound systems.
• Reliable system connectivity: Dual NL4 Speakon®-compatible connectors simplify loudspeaker wiring and system expansion.

Product Specification
