Passive Column Speaker FS-84

Highlight Features

Passive Column Speaker FS-84

The FS-84 is a high-output passive column speaker developed for large spaces where long-throw speech projection and controlled sound coverage are essential. Its eight 4-inch woofers, neodymium compression driver, and exceptional 105 dB sensitivity deliver powerful acoustic output from a slim enclosure. The speaker is suitable for auditoriums, houses of worship, conference halls, live events, public venues, and compact line array systems.

Product Description

• Eight-driver column configuration: Eight 4-inch woofers work together to increase vocal projection, midrange presence, and overall sound output across larger listening areas.
• Detailed high-frequency reproduction: A 1-inch neodymium compression driver provides clear speech articulation and precise reproduction of musical detail.
• Exceptional acoustic sensitivity: With a sensitivity of 105 dB, the FS-84 produces high sound pressure while using amplifier power efficiently.
• High-output performance: The speaker reaches 120 dB continuous and 128 dB peak SPL, supporting demanding professional sound reinforcement applications.
• Focused sound coverage: The 80° horizontal by 30° vertical dispersion pattern directs sound toward the audience while reducing unwanted ceiling and floor reflections.
• Wide programme response: A frequency response of 70 Hz–20 kHz supports intelligible speech, detailed music, and general full-range audio reproduction.
• Durable plywood enclosure: The CNC-machined high-density plywood cabinet provides structural rigidity and consistent acoustic performance.
• Flexible suspension installation: Fourteen M8 threaded rigging points support secure mounting in permanent and portable sound systems.
• Professional connectivity: Dual NL4 Speakon®-compatible connectors simplify system wiring and loudspeaker linking.

Product Specification
