SC-260 Amplifier

Highlight Features

SC-260 – 260W Class AB Mixer Amplifier for 70V / 100V PA Systems

The SC-260 is a high-power Class AB mixer amplifier designed for small to medium public address and background music systems.
Delivering a rated output power of 260W at 1% THD, it provides stable, clear, and consistent sound performance for daily operation in offices, schools, retail stores, and commercial installations. With support for 70V / 100V constant-voltage systems as well as low-impedance speaker outputs, C-260 is suitable for larger zones requiring higher sound coverage.

Key Features:

• High-power Class AB mixer amplifier for PA and background music applications.

• Rated Power: 260W (1% THD), suitable for medium to large PA systems.

• Multiple input options: 2 × MIC IN, 3 × AUX IN, USB IN, and SD IN.

• Flexible speaker outputs: COM / 4–16Ω, 70V / 100V.

• 2-band tone control: Bass and Treble adjustment for simple sound tuning.

• Integrated media features: Bluetooth, FM Radio, and LCD display.

• Full protection circuitry: Ensures safe and stable operation.

• CHIME button for instant announcements or attention signals.

Technical Specifications:

• Model: SC-260

• Series: SC Amply

• Rated Power: 260W (1% THD)

• Chassis: Steel case; aluminum front panel; aluminum handle; plastic knobs

• I/O Connections: 2 × MIC IN; 3 × AUX IN; USB IN; SD IN; 1 × AUX OUT

• Speaker Outputs: COM / 4–16Ω, 70V / 100V

• Tone Control: 2-band EQ: Bass, Treble

• Channels: 1 channel

• MP3 & Media Features: Bluetooth, FM Radio, LCD Display, Remote Controller (optional, 5 RMB)

• Amplifier Section: Class AB Amplifier

• Audio Performance: Frequency Response: 20Hz – 20kHz; THD: <1% at 1/3 rated voltage

• Input Sensitivity: +5 mV, 6.3 mm unbalanced connector
• AUX Input: 400 mV, unbalanced RCA connector

• Protection: Full protection circuitry: Short circuit / Overload / Overcurrent / DC fault

• Additional Features: CHIME Button

• Color: Black / Silver

• Dimensions (W × H × D): 58.5 × 46.5 × 36 cm
• Net Weight: 6.20 kg
